Kramer TP-780T 4K60 HDMI Tx over HDBaseT

The Kramer TP-780T is a high-performance, long-reach HDBaseT transmitter for 4K60Hz (4:2:0) HDMI, RS-232 and IR signals over twisted pair. TP-780T converts all input signals into the transmitted HDBaseT signal. It extends video signals to up to 40m (130ft) over CAT copper cables at up to 4K@60Hz (4:2:0) 24bpp video resolution and provides even further reach for lower HD video resolutions.

Perfect for:
Long-distance AV signal extension for multi-room, large dividable auditoriums and lecture hall connectivity
AV extension in conference rooms, boardrooms, control rooms, hotels and large church facilities

Features:

High Performance Standard Extender - Professional HDBaseT extender for providing long-reach signals over twisted-pair copper infrastructures. TP-780T is a standard extender that can be connected to any market-available HDBaseT-compliant extension product. For optimum extension reach and performance, use recommended Kramer cables.
HDMI Signal Extension - HDCP 2.2 compliant. Supports deep color, x.v.Color™, lip sync, HDMI uncompressed audio channels, Dolby TrueHD, DTS-HD, 2K, 4K, and 3D as specified in HDMI 2.0. EDID and CEC signals are passed through from the source to the display.
I-EDIDPro™ Kramer Intelligent EDID Processing™ - Intelligent EDID handling, processing and pass-through algorithm that ensures Plug and Play operation for HDMI source and display systems.
Multi-channel Audio Extension - Up to 32 channels of digital stereo uncompressed signals for supporting studio-grade surround sound.
Bidirectional RS-232 Extension - Serial interface data flows in both directions, allowing data transmission and device control.
Bidirectional Infrared Extension - IR interface data flows in both directions, allowing remote control of peripheral devices located at either end of the extended line.
Cost-effective Maintenance - Status LED indicators for HDMI and HDBT ports facilitate easy local maintenance and troubleshooting. Local firmware upgrade via RS-232 connection and the K-Upload tool ensures lasting field-proven deployment.
Easy and Elegant Installation - Single cable connectivity for both HDBaseT signals and power. Compact MegaTOOLS™ fan-less enclosure for dropped-ceiling mounting, or side-by-side mounting of 2 units in a 1U rack space with the recommended rack adapter.

Specifications:

INPUTS
1 HDMI on an HDMI connector
OUTPUTS
1 HDBT on an RJ-45 female connector
PORTS
1 IR on a 3.5mm mini jack for IR link extension,
1 RS-232 on a 9-pin D-sub connector for serial link extension and device firmware upgrade
EXTENSION LINE
HDBaseT 1.0 compliant
Up to 40m (130ft) at 4K @60Hz (4:2:0)
Up to 70m (230ft) at full HD (1080p @60Hz 36bpp)
Note: When using Kramer HDBaseT cables
VIDEO
Up to 10.2Gbps bandwidth (3.4Gbps per graphic channel)
Up to 4K UHD @60Hz (4:2:0) 24bpp resolution
HDCP 2.2 signal compliance
Supports deep color, x.v.ColorT, lip sync, HDMI uncompressed audio channels, Dolby TrueHD, DTS-HD, 2K, 4K, and 3D as specified in HDMI 2.0
EXTENDED RS-232
300 to 115200 baud rate
CONTROL RS-232
115200 baud rate
POWER SOURCE
48V DC, 1.36A
POWER CONSUMPTION
48V DC, 240mA
ENCLOSURE
Mega Tools size, aluminum type
COOLING
Convection ventilation
OPERATING TEMPERATURE
0° to 40°C (32° to 104°F)
STORAGE TEMPERATURE
-40° to +70°C (-40° to 158°F)
HUMIDITY
10% to 90%, RHL non-condensing

Item Includes:

TP-780T Transmitter
Power Supply

Warranty:

Limited 7 Year Warranty

The Kramer TP-780T 4K60 HDMI Tx over HDBaseT is a cutting-edge product designed for long-distance AV signal extension. With its high-performance capabilities, this transmitter is perfect for multi-room setups, large auditoriums, conference rooms, control rooms, hotels, and large church facilities.

One of the standout features of the TP-780T is its ability to convert all input signals into a transmitted HDBaseT signal. This ensures that video signals are extended to distances of up to 40m (130ft) over CAT copper cables at resolutions of up to 4K@60Hz (4:2:0) 24bpp. For lower HD video resolutions, the TP-780T can reach even further.

This transmitter is a standard extender that can be connected to any market-available HDBaseT-compliant extension product. It also supports HDCP 2.2 compliance, deep color, x.v.Color™, lip sync, HDMI uncompressed audio channels, Dolby TrueHD, DTS-HD, 2K, 4K, and 3D as specified in HDMI 2.0. The EDID and CEC signals are passed through from the source to the display.

The TP-780T also comes with extensive audio capabilities, supporting up to 32 channels of digital stereo uncompressed signals for studio-grade surround sound. In terms of control, it offers bidirectional RS-232 and infrared extension, allowing for data transmission, device control, and remote control of peripheral devices.

Not only is the TP-780T a high-performance extender, but it also comes with cost-effective maintenance features such as status LED indicators for easy local maintenance and troubleshooting. It also supports local firmware upgrades via RS-232 connection and the K-Upload tool, ensuring lasting field-proven deployment.

Installation is both easy and elegant with the TP-780T. It features single cable connectivity for both HDBaseT signals and power, and its compact MegaTOOLS™ fan-less enclosure allows for dropped-ceiling mounting. Alternatively, two units can be side-by-side mounted in a 1U rack space with the recommended rack adapter.

In terms of specifications, the TP-780T features 1 HDMI input, 1 HDBT output, 1 IR port for IR link extension, and 1 RS-232 port for serial link extension and device firmware upgrade. It is HDBaseT 1.0 compliant and supports up to 40m (130ft) at 4K@60Hz (4:2:0) and up to 70m (230ft) at full HD (1080p@60Hz 36bpp).

The TP-780T comes with a limited 7-year warranty and includes the transmitter and a power supply. With its exceptional performance, versatility, and ease of installation, the Kramer TP-780T is a must-have for any AV professional looking to extend signals over long distances.

Enhance your AV experience with the Kramer TP-780T, a top-tier long-reach HDBaseT transmitter designed for seamless 4K60Hz HDMI transmission. Perfect for multi-room setups, large auditoriums, and conference rooms, this device extends video signals up to 130ft over CAT cables.

Key features include:

- Professional-grade HDBaseT extender
- HDCP 2.2 compliant with support for deep color and various audio formats
- Intelligent EDID handling for effortless Plug and Play
- Bidirectional RS-232 and IR extension for device control
- Status LED indicators for easy troubleshooting

Upgrade your connectivity with the reliability and performance of the Kramer TP-780T.
